/ Product catalogue / Commercial and industrial ventilation / Inline fans / For round duct / Centro-MZ EC / Centro-MZ EC 125
| Unit of measurement | Centro-MZ EC 125 | |
| Phases | - | 1 |
| Minimum supply voltage | V | 230 |
| Maximum supply voltage | V | 230 |
| Power supply frequency | Hz | 50/60 |
| Weight | kg | 2.5 |
| Transported air temperature (max) | °С | 60 |
| Transported air temperature (min) | °С | -25 |
| Ingress protection rating | - | IPX4 |
| Impeller material | - | Plastic |
| Trademark | Blauberg |
| Model | Centro-MZ EC 125 |
| Type of drive installed | External MSD or VSD |
| Type of heat recovery system | None |
| Nominal external pressure (Pa) | 361 |
| Maximum external leakage rates (%) | 2.7 |
| Static efficiency (%) | 26.2 |
| Effective electric power input (kW) | 0.077 |
| Sound power level (dB(A)) | 65 |
| Declared typology | NRVU UVU |
| Ø D | Ø D1 | H | L | L1 | L2 |
|---|---|---|---|---|---|
| 124 | 245 | 300 | 190 | 20 | 20 |
| Name | Photo | Description |
|---|---|---|
| Blauberg WKH 125-2 |
|
Duct water heaters for round ducts |
| Blauberg WKH 125-4 |
|
Duct water heaters for round ducts |
| Name | Photo | Description |
|---|---|---|
| Blauberg K 125 |
|
Clamp for round flexible ducts |
